無刷直流電機型號選型表：
|
型號
Model |
老型號
old Model |
額定電壓
Rated
Voltage
(V) |
額定功率
Rated
Power
(W) |
額定轉速
Rated
Speed
(rpm) |
額定轉矩
Rated
Torque
(Nm) |
額定電流
Rated
Current
(A) |
空載電流
Non-Load
Current
(A) |
空載轉速
Non-Load
Speed
(rpm) |
|
|
57BL52-212 |
24 |
22 |
1200 |
0.15 |
1.2 |
0.1 |
3000 |
|
|
57BL52-230 |
24 |
60 |
3000 |
0.18 |
3.2 |
0.1 |
4800 |
|
|
57BL70-225 |
24 |
100 |
2500 |
0.4 |
5 |
0.2 |
3000 |
|
|
57BL70-230 |
24 |
100 |
3000 |
0.4 |
5 |
0.2 |
4600 |
|
|
57BL70-336 |
36 |
145 |
3600 |
0.4 |
5.3 |
0.2 |
4600 |
|
|
57BL90-210 |
24 |
60 |
1000 |
0.6 |
3.3 |
0.2 |
1600 |
|
|
57BL90-230 |
24 |
180 |
3000 |
0.6 |
8 |
0.3 |
4200 |
|
57BL90S10-320TF0 |
57BL90-320 |
36 |
100 |
2000 |
0.6 |
|
0.5 |
6200 |
|
|
57BL110-230 |
24 |
210 |
3000 |
0.7 |
11 |
0.3 |
4600 |
|
|
60BL100-230 |
24 |
150 |
3000 |
0.5 |
8 |
0.8 |
4000 |
|
|
60BL100-230SC |
24 |
150 |
3000 |
0.5 |
8 |
0.8 |
4000 |
|
60BL100S15-330TF0 |
60BL100-330 |
36 |
150 |
3000 |
0.5 |
|
0.5 |
3500 |
|
|
60BL120-430 |
48 |
250 |
3000 |
0.75 |
7 |
0.5 |
3500 |
|
|
60BL120-3130 |
310 |
250 |
3000 |
0.75 |
1.5 |
0.2 |
3500 |
|
|
80BL130-330 |
36 |
350 |
3000 |
1.2 |
13 |
0.5 |
3800 |
|
|
80BL145-440 |
48 |
550 |
4500 |
1.2 |
15 |
1.4 |
6000 |
|
|
80BL145-3130 |
310 |
550 |
3000 |
1.6 |
2.4 |
0.6 |
5000 |
|
|
80BL165-3130 |
310 |
750 |
3000 |
2.5 |
3.2 |
0.3 |
4200 |
|
|
80BL165-3115 |
310 |
550 |
1500 |
3.5 |
2.4 |
0.3 |
2100 |
|
|
400w |
48 |
400 |
4500 |
0.8 |
11 |
1 |
5900 |
|
80BL89S25-430TK0 |
250W |
48 |
250 |
3000 |
0.75 |
7 |
0.5 |
4300 |
|
|
500W |
48 |
500 |
4500 |
1.2 |
15 |
1 |
5900 |
|
57BL122R18-332TF0 |
57無刷電機 |
36 |
180 |
3200 |
0.54 |
6.5 |
0.5 |
4300 |
|
|
57BL110-3150 |
310 |
300 |
5000 |
0.7 |
1.3 |
0.3 |
5000 |
以上電機均可以配套行星減速器，相關文章訪問以下鏈接：
http://www.gfzfw.cn/bbs_read.asp?id=4801
http://www.gfzfw.cn/bbs_read.asp?id=4810
http://www.gfzfw.cn/bbs_read.asp?id=4805
購買網址：
http://zgbjdj.com/news2.asp?id=9440/
姓名：李先生
手機：18801063276
qq: 928221169
郵箱：928221169@qq.com
淘寶網址：http://zgbjdj.com/news2.asp?id=9440
|
